114mm Metric Johnny Square® Laser Etched Trim Square
This compact 114mm trim square is ideal for access in tight quarters for finish carpentry, setting saw blades and more. CNC machined from extruded aluminum and has the same anti-glare protective anodized coating that made our Johnny Square® famous, this laser-etched square is durable enough to withstand any jobsite abuse and is backed by Johnson's best-in-class limited lifetime warranty. This rafter square also features continuous scribing notches in 5mm increments that are ideal for ripping lumber as well as easily identified layout marks for the most common lumber and sheet good dimensions
+ Hover over main image to zoom
Solid aluminum body with CNC machined edges for greater accuracy and durability
Hi-visibility EZ-Read™ 1mm graduations and numbers are laser etched deep into the surface for greater durability
Continuous scribing notches from 10mm to 90mm in 5mm increments
Black anodized aluminum with low-glare matte finish
22.5°, 30°, 45°, 60°, and 67.5 slots for marking out commonly used angles
Layout markings for common dimensions
Easily identifiable markings and notches for layout, scribing and marking cuts
Erasable space for writing finish notes
9mm and 6mm dual heel sizes for setting reveals
| Warranty: | Limited Lifetime Warranty |
|---|
Johnson's 114mm Johnny Square® is a versatile tool for builders and contractors. This compact trim square is ideal for access in tight quarters for finish carpentry, setting saw blade angles and more.
