Short Magnetic Locator with LCD

Short Magnetic Locator with LCD

Model: 40-6430

Johnson's Short Magnetic Locator with LCD display will detect any ferrous metal underground and is perfect for locating survey corner markers, PK and Mag Nails, Valve boxes and cub boxes, steel and iron pipes, well castings, steel tanks, lost tools or even downed and buried fence lines.  This magnetic locator is more lightweight than other commericial magnetic locators and features a rugged construction that is suitable for harsh field conditions - this magnetic locator can be submerged in water up to 75 feet.  This easy-to-use magnetic locator features a four button keypad and non-slip hand grip - perfect for one handed operation.

  • Flashing LCD when batteries need replacement
  • Varying pitch audio signmal mode using a moving coil speaker for enhanced audio output
  • Waterproof - sensor tube pressure tested to water depths up to 75 feet
  • Easy to use - one handed operation with four button keypad
    On/Off button - turns unit on or off
    Zero button - automatically calibrates unit to ambient magnetic conditions
    Gain up button - increases the locating sensitivity of unit                                              Gain down button - decreases the locating sensitivity of unit
  • Rugged construction suitable for field conditions
  • Non-slip hand grip
  • Detection of buried ferrous metal objects at depths up to 8 feet
    Hand gun - one to two feet
    175 mm projective - four to five feet
    55 gallon drum - six to ten feet
  • Detection of ferrous metal objects and weapons on persons
  • Underwater search and detection of submerged vehicles, UXO's and mines, salvageable wrecks, pipes and cables
  • Limited lifetime warranty
Magnetic Locator
Magnetic Locator with LCD
Long Magnetic Locator with LCD

Johnson Level's 40-6430 Short Magnetic Locator with LCD includes:

  • Short magnetic locator with LCD
  • (3) 9V (2 spare) alkaline batteries
  • Instruction manual
  • Soft-sided carrying case

Magnetic Locator Applications:

Detecting any ferrous metal object above or under the ground such as locating survey corner markers, PK and Mag Nails, valve boxes and curb boxes, steel and iron pipes, well casings, steel tanks, lost tools and downed and buried fence lines.

Johnson Level Rapid Response Center for Repair and Service

In the U.S., call 888-953-8357 from 8AM-5PM CT. In Canada, call 514-695-7221 8AM-5PM ET.
