Self-Leveling 5 Dot Laser

MODEL #:  40-6678

Locking compensator protects pendulum during transport. Multi-functional magnetic base. Laser housing design allows fast and easy top and bottom track installation. Reversible bracket for flush track drywall/framing. Set plumb, level, and square. 40-6678 INCLUDES > Laser, multi-functional magnetic base, 3 "AA" alkaline batteries, mounting strap, and hard-shell carrying case.

w/beam+ Hover over main image to zoom
w/beam
w/kit
  • Locking compensator protects pendulum during transport

  • Multi-functional magnetic base

  • Laser housing design allows fast and easy top and bottom track installation

  • Reversible bracket for flush track drywall/framing

  • Set plumb, level, and square

40-6678 INCLUDES > Laser, multi-functional magnetic base, 3 "AA" alkaline batteries, mounting strap, and hard-shell carrying case

Leveling Method:

Self-Leveling (Pendulum)

Laser Wavelength:

635nm±10nm (Red)

Laser Classification:

Class IIIa

Maximum Power Output:

≤5mW

Accuracy:

±1/8"/50'

Interior Range:

Up to 100'

Self-Leveling Range:

±3°

Power Supply:

3 "AA" alkaline batteries (included)

Battery Life:

50 hours continuous use

Dimensions:

5.00" x 1.97" x 5.76"

Weight:

1.43 lbs

Working Temperature:

14° F to 113° F

IP Protection Class:

IP 54

Warranty:

3 Years

The Johnson Level 40-6678 can be used for the following indoor and outdoor applications; setting foundations and footings, alignment of concrete forms, layout of interior walls, room additions/partition installation, install sprinkler systems, HVAC, plumbing and pipe installation, machinery installation, electrical outlets and switches, install conduit and wiring, track and canned lighting, align brick, square up battered boards, align fences, plumb posts and pickets, align 90 degree joints and edges, level cabinets, shelving and countertops.

Johnson Level Rapid Response Center for Repair and Service
In the U.S., email us at service@johnsonlevel.com or call 888-953-8357 M-F from 9AM-3PM CT.
In CANADA, call 800-346-6682 x347 M-F 8AM-5PM ET.

40-6678 User Manual-English
40-6678 User Manual- Spanish
40-6678 User Manual- French


Replacement Hard-Shell Carrying Case for 40-6678 Model: 40-6789 $52.44
replacement multi-functional magnetic base
Replacement Multi-Functional Magnetic Base for 40-6692, 40-6693, 40-6695, 40-6678 Model: 40-6307 $18.00


Product Details

Locking compensator protects pendulum during transport. Multi-functional magnetic base. Laser housing design allows fast and easy top and bottom track installation. Reversible bracket for flush track drywall/framing. Set plumb, level, and square. 40-6678 INCLUDES > Laser, multi-functional magnetic base, 3 "AA" alkaline batteries, mounting strap, and hard-shell carrying case.



40-6678 INCLUDES > Laser, multi-functional magnetic base, 3 "AA" alkaline batteries, mounting strap, and hard-shell carrying case

Specifications

Leveling Method:

Self-Leveling (Pendulum)

Laser Wavelength:

635nm±10nm (Red)

Laser Classification:

Class IIIa

Maximum Power Output:

≤5mW

Accuracy:

±1/8"/50'

Interior Range:

Up to 100'

Self-Leveling Range:

±3°

Power Supply:

3 "AA" alkaline batteries (included)

Battery Life:

50 hours continuous use

Dimensions:

5.00" x 1.97" x 5.76"

Weight:

1.43 lbs

Working Temperature:

14° F to 113° F

IP Protection Class:

IP 54

Warranty:

3 Years

Application

The Johnson Level 40-6678 can be used for the following indoor and outdoor applications; setting foundations and footings, alignment of concrete forms, layout of interior walls, room additions/partition installation, install sprinkler systems, HVAC, plumbing and pipe installation, machinery installation, electrical outlets and switches, install conduit and wiring, track and canned lighting, align brick, square up battered boards, align fences, plumb posts and pickets, align 90 degree joints and edges, level cabinets, shelving and countertops.

Support

Johnson Level Rapid Response Center for Repair and Service
In the U.S., email us at service@johnsonlevel.com or call 888-953-8357 M-F from 9AM-3PM CT.
In CANADA, call 800-346-6682 x347 M-F 8AM-5PM ET.

40-6678 User Manual-English
40-6678 User Manual- Spanish
40-6678 User Manual- French


Replacement Parts

Replacement Hard-Shell Carrying Case for 40-6678 Model: 40-6789 $52.44
replacement multi-functional magnetic base
Replacement Multi-Functional Magnetic Base for 40-6692, 40-6693, 40-6695, 40-6678 Model: 40-6307 $18.00
